200kw 15000rpm IP54 High Power High Speed Blower Motor Pmsm

Product Overview

Basic Introduction of the PMSM Blower Motor

This 200KW High-Speed PMSM Blower Motor (Model: SRPM205H4O200) launched by MC MOTOR is a high-performance industrial drive solution designed for heavy-duty high-speed operating scenarios. As a core component of industrial blower systems, it integrates advanced permanent magnet synchronous motor (PMSM) technology to achieve a perfect balance between power output and energy efficiency.

Core Advantages & Market Position

With a rated speed of 15000rpm and an impressive efficiency of96%, the motor outperforms conventional induction motors in energy conversion and continuous power supply. It features IP54 water and dust protection and H-class insulation, ensuring stable operation in harsh industrial environments such as high dust, humidity, and temperature fluctuations. Equipped with a patented oil cooling structure, the motor effectively controls temperature rise during high-speed operation, while its compact design and low noise vibration characteristics meet the strict requirements of modern industrial equipment for high reliability and low maintenance costs.

Key Product Features

15000rpm High-Speed Adaptability & Stable Operation

The motor is specially optimized for high-speed working conditions, with a rotor moment of inertia less than 0.08kg·m², ensuring fast response, no speed fluctuation, and stable operation even at the maximum speed of 15000rpm. The optimized rotor structure reduces air resistance, further improving the overall operating efficiency and service life.

High Power & High Torque Output Capacity

With a rated power of 200KW and 4 poles, it delivers strong and continuous torque, perfectly matching the needs of large-scale blowers, compressors, and other heavy industrial equipment. The high torque output at low speed ensures smooth startup without additional auxiliary equipment, reducing the overall investment cost for users.

Efficient & Energy-Saving Performance

Adopting advanced PMSM technology and precision winding design, the motor achieves a high efficiency of 96%, which is 8-10% higher than that of traditional motors. This high efficiency significantly reduces energy consumption during long-term continuous operation, lowering the overall operating costs for users and complying with global energy-saving and environmental protection standards.

Patented Oil Cooling & Durable Structure

Adopting VG32 (Mobil) lubricating oil for cooling, the motor strictly controls the inlet oil temperature between 40-45°C, effectively extending the service life of bearings and windings. The sealed oil circulation system prevents oil leakage and ensures stable cooling performance even in high-temperature working environments.

Low Noise, Low Vibration & Easy Maintenance

The product features low noise (≤75dB at 1m) and low vibration during operation, creating a comfortable working environment. The oil change cycle is as long as 18000h, with the first oil change only needed after 8000h of operation, reducing maintenance frequency and labor costs. The detachable structure allows for quick inspection and replacement of wearing parts.

Technical Specifications

Parameter Details of 200KW High-Speed PMSM Blower Motor

Application Scenarios

Industrial Blowers & Compressors

Providing stable high-speed power for large-scale air compression and delivery equipment, such as centrifugal blowers, screw compressors, and roots blowers, which are widely used in chemical, metallurgical, and cement industries.

High-End Manufacturing Equipment

Matching precision processing equipment that requires high power and high speed, such as CNC machine tools, precision grinders, and industrial robots, improving processing efficiency and product precision.

Energy Systems

Being used in energy conversion equipment such as wind power and thermal power auxiliary systems, providing reliable drive support for energy collection and transmission, and improving the stability of the energy system.

Heavy Machinery

Serving as the power core of mining, metallurgy and other heavy machinery supporting equipment, such as mine ventilation blowers, metallurgical furnace blowers, adapting to harsh working environments and ensuring continuous operation of equipment.

Brand & Quality Assurance

Brand Strength & R&D Capability

MC MOTOR is a professional manufacturer focusing on the R&D, production, and sales of high-performance industrial motors, with more than 15 years of industry experience. The company has a professional R&D team composed of senior engineers, constantly innovating and optimizing product technology to meet the changing needs of the global market.

Strict Quality Inspection Standards

This motor has passed strict performance and reliability tests, including high-temperature test, vibration test, noise test, and durability test, ensuring that each product meets international quality standards. The H-class insulation design enhances the motor's heat resistance, and the configuration of three-wire PT100 winding temperature sensors and double six-wire PT100 bearing temperature sensors realizes real-time monitoring of the motor's operating status.

Patent Protection & Reliability Guarantee

The motor is equipped with three thrust bearings and one steady bearing of A-class precision, which can withstand an axial force of 5000N, ensuring long-term stable operation. The product has obtained a patent for its cooling structure (Patent No.: ZL20242XXXXXX), and its durability and reliability have been fully verified in practical applications.

Purchasing & Logistics Guide

Delivery Time

Sample order: In-stock goods can be delivered within 1-3 days; customized products require 45-60 days, depending on the customization requirements. Mass production order: Delivery takes 15-25 days, specifically based on the order quantity (the more the quantity, the more preferential the delivery cycle).

Transportation Method

By air: DHL/FEDEX/UPS/TNT and other door-to-door delivery services are available, with a delivery time of 3-7 days, suitable for urgent orders. By sea: Both LCL and FCL transportation are supported, meeting the different logistics needs of customers, with a delivery time of 20-40 days, suitable for large-batch orders.

Payment Method

Acceptable payment methods include T/T, WESTERN UNION, PAYPAL and L/C at sight, which is convenient for global customers to pay. For orders over 5000USD, the payment term is 30% deposit in advance and 70% balance before shipping; for small orders, full payment in advance is required.

Call to Action

Why Choose Our 200KW High-Speed PMSM Blower Motor?

If you are looking for a high-power, high-speed and high-efficiency blower motor for your industrial equipment, the SRPM205H4O200 High-Speed PMSM Motor from MC MOTOR is your ideal choice. It combines energy-saving, durability, and high performance, helping you reduce operating costs and improve production efficiency.

Contact Us & Place Order

Contact us now to inquire about detailed product information, customized solutions and preferential prices. Click "Add to Basket" to place your order, and we will provide you with professional pre-sales consultation and after-sales service. Our 24-hour customer service team is always ready to answer your questions!
